MM3D

MM3D is a 3D marking software based on MarkingMate.

Features

• Precise positioning
• Use second CCD for improving positioning speed
• Lens correction with CCD
• Multi work position support
• Split large picture output support
• Precise marking, drilling and cutting

Components

• Industrial camera
• CCD Lens extension rings
• MarkingMate Professional marking software
• PMC2 marking control card

Versions

Version	Feature	Component
EL-CVP Lite	1. Up to two camera support 2. Target visual compare with XY-Table control	- U36 Camera x 1 - 3519 camera lens and lens extension rings x 1
EL-CVP Advance	1. Up to two camera support 2. Target visual compare with XY-Table control 3. Lens correction 4. Camera correction	- U36 Camera x 1 - 3519 lens and lens extension rings x 1 - MarkingMate and PMC2 boards
EL-CVP Professional	1. Up to two camera support 2. Target visual compare with XY-Table control 3. Split large picture output 4. Camera correction 5. Lens correction	- U36 Camera x 1 - 3519 lens and lens extension rings x 1 - MarkingMate and PMC2 boards

Comparision

Version	Multi work position	Split picture output	Lens Correction	Camera Correction
EL-CVP Lite	✔️	❌	❌	❌
EL-CVP Advance	✔️	❌	✔️	✔️
EL-CVP Professional	✔️	✔️	✔️	✔️
